Parrameters | Unit | SUN-FSW-MEMS-1×N(≤16) | |||
| Wavelength Range | nm | SM | MM | ||
| 1260~1650 | 850±20 or 1310±20 or 1550±20 | ||||
| Test Wavelength | nm | 1310/1550 | 850/1310/1550 | ||
| Insertion Loss | dB | 0.6(TYP) 0.8(MAX) N≤8 1.0（TYP） 1.6(MAX) N≤16 | 0.8（TYP） 1.0(MAX) N≤8 1.0（TYP） 1.5（MAX） N≤12 | ||
| Repeatability | dB | ≤±0.05 | ≤±0.05 | ||
| Return Loss | dB | ≥40 | ≥25 | ||
| Crosstalk | dB | ≥50 | ≥30 | ||
| WDL | dB | ≤0.3 | ≤0.3 | ||
| PDL | dB | ≤0.15 | ≤0.15 | ||
| Switching Time | ms | ≤20 | |||
| Durability | Cycles | ≥109 | |||
| Transmission Power | mW | ≤500 | |||
| Power Supply | V | 5~12 | |||
| Operating Temperature | ℃ | -5~+70 | |||
| Storage Temperature | ℃ | -40~+85 | |||
| Dimension | mm | S1:(Type A) 39.1 x 24.7 x 11 ±0.2 | |||
| S1:(Type B) 65 x 24.7 x 11 ±0.2 | |||||
| S2:(Type A) 90 x 50 x 12 ±0.2 | |||||
Notes: 1. Within operating temperature and SOP，MM CPR＞16. 2. Excluding connectors. 3. Power off isolation same as cross-talk. 4. WDL is specified in a ±20 nm of 1550nm,at 23°C. 5. Repeatability is defined after 100 cycles. | |||||
| N:Output Number | A: Fiber Type | B: Package Type | C: Test Wavelength | D: Tube Type | E: Fiber Length (Include connector) | F: Connector | G:Interface |
4:4 8:8 12:12 16:16 X: Others | SM: SM, 9/125 M5: MM, 50/125 M6: MM, 62.5/125 X: Others | A: Type A B: Type B | 850: 850nm 1310: 1310nm 8513: 850&1310nm 1550: 1550nm 1315: 1310&1550nm X:Others | 25:250um (Type A ) 90:900um (Type B) X: Others | 05: 0.5m±5cm 10: 1.0m±5cm 15: 1.5m±5cm X: Others | OO: None FP: FC/PC FA: FC/APC SP: SC/PC SA: SC/APC STP: ST/PC LP: LC/PC LA: LC/APC X: Others | TTL : TTL/UART I2C : I2C/UART UART : UART |
DWDM networks
Channel Monitor
R&D in Laboratory
Configurable OADM
◆Base on MEMS technology
◆Small package
◆High Stability, High Reliability
◆Epoxy-free on Optical Path
◆Non-latching
